Liquid Level Sensor Cable PE / DQYPY 5*0.2mm²-7/0.2TS-7.4-Black
PE / DQYPY 5*0.2mm²-7/0.2TS-7.4-Black
Equipped with advanced wire and cable production equipment, these equipment have high-precision control and automated production capabilities. In the conductor production process, advanced wire drawing machines and stranding machines can accurately control the diameter and stranding quality of copper wire to ensure the consistency and stability of conductor specifications. In the insulation and sheath extrusion process, the extruder used can accurately control the extrusion volume and thickness of the material to ensure the uniformity and integrity of the insulation layer and sheath.
Compensation wire, compensation cable and thermocoupleequipment are used for temperature measurement and controlsystems in electric power, metallurgy, petroleum, chemical,textile of some factories and scientific research departments.The compensate cable is simple and easy to lay, resistantwith moisture resistant,acid and alkali, high temperatureand aging,it is good at shielding to prevent outside
interference.
Temperature:
Fire-resistant,heat-resistanttype FF-GS -40℃~ +250°C
Fire-resistant,hightemperature-resistantHF4B-GS-40℃~ +380℃
Commontype -20℃~+100°C
Representation oftype,name and specifications:
The type of thermocouple and RTD: compensation wire for S、 R.B、K、E、J、Tand EA-type thermocouple using.
Insulation:
Divided into: FEP,PTFE, Polyimide Pl, etc.Screen:
Dividedinto:Tin/Nickel/304 stainless steel,aluminum
(single, double),etc.
Layers:single, double weaving
Weaving density:70%，80%，90%，95%etcRepresentation of type,name and specifications:
The type ofthermocouple and RTD: compensation wire for S、R.B、K、E、J、Tand EA-type thermocouple using.
